Perspex 20w Co2 Laser Marking Systems CE ISO Approved

Basic Information
Place of Origin: tianjin, China
Brand Name: SUNDOR
Certification: ce, ISO
Price: $2,500.00/sets 1-4 sets
Packaging Details: 1. Packaging with factory Metal Nameplate; 2. Standard export wooden cases with sponge filled inside for packing protection 3. The Wooden case is fumigation free. Suitable both by sea and by air.
Supply Ability: 300 Set/Sets per Month
Detail Information
Laser Type: CO2 CNC Or Not: Yes
Cooling Mode: Air Cooling Control Software: EZCAD
Laser Source Brand: CRD Name: Perspex 20w Co2 Laser Marking Systems CE ISO Approved
Wavelength: 10.6 μm Laser Repetition Frequency:: 20KHz-80KHz(adjustable)
Power Demand: AC220V/50HZ/2A Laser Power: 20W
High Light:

20w co2 laser marking systems

,

perspex co2 laser marking systems

,

20w co2 marking machine


Product Description



Perspex 20w Co2 Laser Marking Systems CE ISO Approved





co2 marking machine Product Description


Product Name Perspex 20w Co2 Laser Marking Systems CE ISO Approved
Laser Type CO2
Modol YLH-L
Certificatons CE, ISO,OTHER
Power ≥20W
Brand SUNDOR
Work Precision ±0.01mm
Support Format PLT, DST, AI, DXF, BMP, JPG, CAD,CDR, DWG,PCX
Software EZCAD
Cooling Way AIR COOLING
NC YES
Min Line Width 0.15mm
Min Character 0.2mmx0.2mm
Wavelength 10.6 μm
Laser Repetition Frequency: 20KHz-80KHz(adjustable)
Power Demand AC220V/50HZ/2A
Optimum Working Temperature 10-35 °C
Marking Depth 0.01-1.0mm(subjejct to material)

co2 marking machine Product Features



1.    Marking process in automation, fast speed, high efficiency, good anti-counterfeit;
2.    Stable equipment performances, the optical system can be adjusted as to and fro, up and down, and can be equipped with red light position indicating device;
3.    Adopts advanced digital high speed scanning galvanometer, quick speed without deviation, small volume, good stability, and performance reached the international advanced level.
4.    Modular design, separate laser generator and lifter, more flexible, can mark on bigger area and complicated surface. Air-cooled inside, small occupation, easy to install.
5.    Adopt the embedded operating system, which the performance is leading domestic peers, good touch interface and powerful control system, can meet the demand of most industry application process in market. Control software supports automatic encoding, variable text, date, serial number, lot number, bar code and two-dimensional code printing, and can be modified according to customers’ different needs of production line flexibly.
6.    Adopt special flying marking control system, with good performance and easy operation. Can easily match with producing line and work continuous 24 hours which meets industrialize large-scale production.
7.    High efficiency for photoelectric conversion, simple operation, Compact in structure, support harsh working environment, no consumables.
8.     CO2 laser marking machine performs excellent while marking on transistor, chip component, IC, Ceramic capacitor, thermistor due to its effects of nice extrinsic feature, clear writing and anti-friction. It especially specializes in automatic machining process for marking on bulk packing or strip packing components.



co2 marking machine Product Details



Perspex 20w Co2 Laser Marking Systems CE ISO Approved 0

Perspex 20w Co2 Laser Marking Systems CE ISO Approved 1



Perspex 20w Co2 Laser Marking Systems CE ISO Approved 2


co2 marking machine Product Applications


The equipment is widely used in non-metal materials such as paper, leather, wood product, plastic, Perspex, cloth, acrylic, wood bamboo, rubber, crystal, diamond stone, jade, ceramics, glass, artificial stone and etc.



Perspex 20w Co2 Laser Marking Systems CE ISO Approved 3


Related Products

Perspex 20w Co2 Laser Marking Systems CE ISO Approved 4
Packaging


1. Packaging with factory Metal Nameplate;

2. Standard export wooden cases with sponge filled inside for packing protection.

3. The Wooden case is fumigation free. Suitable both by sea and by air.

Perspex 20w Co2 Laser Marking Systems CE ISO Approved 5

 Perspex 20w Co2 Laser Marking Systems CE ISO Approved 6
